The electromagnetic waves projected by the sun pass through the transparent glass surfaces by radiation, transforming into infrared (heat). This energy leads to a rapid and significant increase in temperature inside the building, which struggles to escape due to the high efficiency of modern insulating glass units (double and triple glazing). The temperature in a room directly exposed to sunlight through windows rises by several degrees in a short time, often making it essential to use a cooling system, which is not always an economical or eco-friendly solution.
Solar Control Films for Glass
Why Choose Solar Control Films for Glass?
From March to October, the impact of solar rays through the windows of homes, offices, schools, and hospitals creates an uncomfortable indoor climate due to the greenhouse effect:
What Are the Benefits of Solar Control Films for Glass?
Energy
Savings
You can save 30% to 50% on your electric bill without removing the glass from the frames. These films have an expected lifespan of over 15 years, with no need to modify your cooling system.
Investment
Amortization
The significant reduction of summer energy load through windows allows the entire installation cost of the films to be amortized within 3 to 5 years. For skylights, the ROI is less than 3 years.
Glare
Reduction
Depending on the characteristics of your building, the type and size of your windows, our consultants can recommend the appropriate films with light, medium, or high anti-glare effects.
Reduction of color shifting
Objects, wall finishes, floors, carpets, artwork, and products displayed in shop windows are subject to “color fading.” Anti-IR and Anti-UV films preserve them over time.
Solutions
Types of Solar Control Films for Glass
Sputtered Films
These are state-of-the-art solar control films for glass. The “sputtering” process allows a denser layer of various precious metals (bronze, titanium, gold, etc.) to be applied to the film with reduced mirror effect and high light transmission. This film provides warm and relaxing light temperature.
Neutral Solar Control Films
These are the most advanced solar control films for glass on the market. They have “zero mirror effect” as they are free of reflective metal oxides. Their functionality relies on 220 transparent polyester layers in only 60 microns of thickness. They are invisible for storefronts or provide an elegant, reflection-free transparency for schools, offices, and museums.
Silver Films
These are metallic solar control films with a mirror effect and high energy efficiency, achieved through an aluminum vapor deposition process. They are highly effective against glare and reflections and provide a cool light temperature.
Technical Data Sheets of Solar Control Films for Glass
Sputtered
NEU BR20 EXT
The NEU BR20 EXT represents the pinnacle of the blend between reflective technology with reduced mirror effect and the elegant chromatic-architectural needs of the “warm” tones of building facades. A special bronze metallization allows for high energy performance and anti-glare properties while maintaining good basic light transmission. Schools, kindergartens, hospitals, nursing homes, and buildings with wooden exterior elements are the most common applications for this innovative film.
Technology: Sputtering
Scratch-resistant: Hard Coating
Average Technical Lifespan: > 10 years
Thickness (excluding liner): 80 microns
Notes: Elegant bronze color with reduced nighttime mirror effect.
Choose the type of glass to install the film on:
Technical duration: 10 years
G Value: 0,16%
Technical duration: 10 years
G Value: 0,12%
Technical duration: 10 years
G Value: 0,09%
Sputtered
NEU BR30 EXT
The NEU BR30 EXT, directly derived from its older sister NEU BR20 EXT, offers an excellent compromise between high reflective energy performance and good light transmission. All this with a low mirror effect in “warm” tones. Ideal for installations in tertiary environments already equipped with anti-glare blinds, or in areas with selective glazing whose energy efficiency is not satisfactory. Ideal for buildings subject to architectural constraints.
Technology: Sputtering
Scratch Resistance: Hard Coating
Average Technical Durability: > 10 years
Thickness (excluding liner): 80 microns
Notes: Elegant bronze coloration – reduced reversal of the nighttime mirror effect.
Choose the type of glass to install the film on:
Technical duration: 10 years
G Value: 0,22%
Technical duration: 10 years
G Value: 0,17%
Technical duration: 10 years
G Value: 0,14%
Double Sputtered
DUR15 EXT
The DUR15 EXT features an internal structure based on double sputtering metallization technology, capable of reducing the reversal of nighttime mirror effect. This innovative film, with its distinct mirror-like reflective effect and low light transmission, has been specifically designed for solar shading of large glass surfaces where it may not be possible to install anti-glare curtains. The DUR15 EXT provides the highest energy reflective and anti-glare performance.
Technology: Double sputtering
Scratch resistance: Hard Coating
Average Technical Durability: > 10 years
Thickness (excluding liner): 80 microns
Notes: Double metallization reduces the reversal of nighttime mirror effect.
Choose the type of glass to install the film on:
Technical duration: 10 years
G Value: 0,11%
Technical duration: 10 years
G Value: 0,08%
Technical duration: 10 years
G Value: 0,05%
Pellicole sputtered
NEU TI20 EXT
La NEU TI20 EXT utilizza la tecnologia “sputtering” della metallizzazione con ossidi in titanio, notoriamente a basso effetto specchio, la quale garantisce una buona riflessione energetica ed una buona azione antiabbaglio / antiriflesso. Ideale per serramenti in colorazione scura e/o per situazioni con vincolo architettonico.
Tecnologia: sputtered
Antigraffio: Hard Coating
Durata Tecnica Media: > 10 anni
Spessore (liner escluso): 80 micron
Note: elegante e ridotto effetto specchio in tonalità titanio con trasmissione di luce “calda” e rilassante
Scegli il tipo di vetro su cui installare la pellicola:
Garanzia con posa: 10 anni
Fattore g: 0,44%
Garanzia con posa: 10 anni
Fattore g: 0,35%
Pellicole sputtered
NEU TI35 EXT
La NEU TI35EXT è direttamente derivata dalla sorella maggiore NEU TI20 EXT, consente di ottenere un ottimo compromesso tra elevate prestazioni energetiche riflettenti, ridotto effetto specchio e buona trasmissione luminosa. Ideale per serramenti in colorazione scura e/o per situazioni con vincolo architettonico.
Tecnologia: sputtered
Antigraffio: Hard Coating
Durata Tecnica Media: > 10 anni
Spessore (liner escluso): 80 micron
Note: elegante e ridotto effetto specchio in tonalità titanio con trasmissione di luce “calda” e rilassante
Scegli il tipo di vetro su cui installare la pellicola:
Garanzia con posa: 10 anni
Fattore g: 0,35%
Garanzia con posa: 10 anni
Fattore g: 0,26%
Neutral films
PR 20 EXT
Wählen Sie den Glasart aus, auf den Sie die Folie anbringen möchten:
Manufacturer warranty: 10 years
G Value: 0,34%
Manufacturer warranty: 10 years
G Value: 0,24%
Manufacturer warranty: 10 years
G Value: 0,16%
Neutral films
PR 40 EXT
The PR40 Exterior is a zero-mirror effect film characterized by an elegant brownish hue without reflective metal oxides. Thanks to its nanotechnology multilayer structure with 220 layers of polyester in just 62 microns thickness, it effectively dampens solar electromagnetic waves in the infrared spectrum, while allowing an ideal amount of glare-free light for educational and commercial buildings. It is particularly suitable for glazings where a perfect compromise between high energy reflection, facade elegance, good glare reduction, but without any mirror effect is required. Energy reflection around 80% with average light transmission around 40%.
Technology: 220 layers of polyester, metal-free
Scratch-resistant: Yes
Average Technical Lifespan: > 15 years
Thickness (excluding liner): 62 microns
Note: Good anti-glare action combined with high selective heat-reflective capability. Does not reduce mobile phone reception
Choose the type of glass to install the film on:
Manufacturer warranty: 10 years
G Value: 0,39%
Manufacturer warranty: 10 years
G Value: 0,29%
Manufacturer warranty: 10 years
G Value: 0,23%
Neutral films
PR 70 EXT
The PR70 Exterior is an almost invisible film with no reflection and no reflective metal oxides. Thanks to its nanotechnology multilayer structure with 220 layers of polyester in just 62 microns thickness, it effectively dampens solar electromagnetic waves in the infrared spectrum while allowing almost all light to pass through. It is particularly suitable for buildings with architectural constraints, residential and educational buildings, and for glazed areas where the original architectural appearance of the building should not be altered in any way. Despite a glass light transmission of 60% to 70%, the energy performances are of paramount importance.
Technology: 220 layers of polyester, metal-free
Scratch-resistant: Yes
Average Technical Lifespan: > 15 years
Thickness (excluding liner): 62 microns
Note: The best compromise between energy reflection and nearly imperceptible architectural impact. Does not reduce mobile phone reception
Choose the type of glass to install the film on:
Manufacturer warranty: 10 years
G Value: 0,39%
Manufacturer warranty: 10 years
G Value: 0,30%
Manufacturer warranty: 10 years
G Value: 0,22%
Neutral films
PR 90 EXT
The PR90EXT is a completely invisible film with no reflection and no reflective metal oxides. Thanks to its nanotechnology multilayer structure with 220 layers of polyester in just 62 microns thickness, it effectively dampens solar electromagnetic waves in the infrared spectrum while allowing all light to pass through. It is ideal for effectively shielding display windows with ultra-clear glass, as it absolutely maintains the transparency and brightness characteristics of the glass. It does not reduce mobile phone reception.
Technology: 220 layers of polyester, metal-free
Scratch-resistant: Yes
Average Technical Lifespan: > 15 years
Thickness (excluding liner): 62 microns
Note: Completely invisible with good energy performance and zero mirror effect. Does not reduce mobile phone reception
Choose the type of glass to install the film on:
Manufacturer warranty: 10 years
G Value: 0,62%
Manufacturer warranty: 10 years
G Value: 0,55%
Manufacturer warranty: 10 years
G Value: 0,45%
Silver Folien
SIL20 EXT
The SIL20 EXT represents the highest performing version of mirror-effect films in silver tone. It ensures maximum energy reflection along with an effective anti-glare/anti-reflection action, ideal for commercial work environments.
Technology: reflective aluminum vapor deposition
Scratch-resistant: Hard Coating
Average Technical Lifespan: > 10 years
Thickness (excluding liner): 80 microns
Note: Ensures maximum energy performance with a strong daytime mirror effect
Choose the type of glass to install the film on:
Manufacturer warranty: 10 years
G Value: 0,13%
Manufacturer warranty: 10 years
G Value: 0,10%
Manufacturer warranty: 10 years
G Value: 0,06%
Silver films
SIL35 EXT
Choose the type of glass to install the film on:
Manufacturer warranty: 10 years
G Value: 0,25%
Manufacturer warranty: 10 years
G Value: 0,22%
Pellicole silver
SIL50 EXT
La SIL50 EXT consente un buon compromesso per le situazioni in cui, oltre alla privacy diurna in tonalità silver chiaro sia necessario anche ottenere buone prestazioni energetiche riflettenti unite ad elevata trasmissione luminosa interna.
Tecnologia: vapori di alluminio riflettente
Antigraffio: Hard Coating
Durata Tecnica Media: > 10 anni
Spessore (liner escluso): 80 micron
Note: garantisce buone prestazioni energetiche con leggero effetto specchio diurno
Scegli il tipo di vetro su cui installare la pellicola:
Garanzia con posa: 10 anni
Fattore g: 0,47%
Garanzia con posa: 10 anni
Fattore g: 0,39%
Garanzia con posa: 10 anni
Fattore g: 0,34%
